Stantsimismasin Benelli 650T/3MR/2/12/3750X1100/LD/ET3

Press equipped with 2 feeing lines - one from the side for blank cutting in transfer mode and one in line for for  progressive die operation.


Press Design
drive system: link drive
openings in uprights: yes
number of slide actions: 2
table cushion: yes
quick die change system: yes
Press forces
total force (nominal): 650 to
Press Table
table surface (left-right): 3700 mm
table surface (front-back): 1100 mm
Slide
stroke: 400 mm
stroke rate (max.): 35 /min
slide (mechan. Press)
slide adjustment: 160 mm
autom. Slide adjustment: yes
stroke adjustment: no
variable speed: yes
stroke rate (min.): 10 /min
stroke rate (max.): 35 /min
main drive power: 99 kW
Tool Assembly Dimensions
shut height (stroke down, adjustment up), BDC: 1100 mm
Transfer System
number of tool stations: 14
Electrical specifications
total power consumption: 130 kW
mains voltage: 400 V
mains frequency: 50 Hz
Dimensions / weights
height above floor level: 7047 mm
height under floor level: 1650 mm
total weight approx.: 155000 kg
Attachments (presses)
autom. tool clamping device: yes
decoiler: yes
leveller unit: yes
strip feeder: yes
feeder type: roll feeder
waste cutter: yes
press automation: yes
gripper transfer system: yes
safety guard / safety door: yes
2-hand engagement: yes
European CE standards: yes
